Specifications
qEngine
Item Specification
Type DOHC-16V in-line, 4-cylinder
Bore×Stroke 87.5 × 83.1 mm (3.44 × 3.27 in)
Displacement 1,999 ml (1,999 cc, 122.0 cu in)
Compression ratio 10.8
qElectrical System
Item Classification
Battery 12V-36AH/5HR
Spark-plug number NGK ILTR6A13G
Spark-plug gap 1.25―1.35 mm (0.049―0.053 in)
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particu late
coating on the iridium allo y and platinum tips could be damaged.
qLubricant Quality
Lubricant Classification
Engine oil Refer to Recommended Oil on page 8-18.
Manual transmission
oil
5-speed
transmission
Any temperature
API Service GL-4 or GL-5
SAE 75W-90
Above 10 °C (50 °F)
API Service GL-4 or GL-5
SAE 80W-90
6-speed transmission
API Service GL-4 or GL-5
SAE 75W-90
Automatic transmission fluid Mazda Genuine JWS3309
Rear differential oil
API Service GL-5
SAE
90
80W-90
75W-90
*1
Power steering fluid
Mazda Genuine ATF M-III or equivalent
(e.g. Dexron® II)
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
*1 Not available from Mazda
10-4
Specifications
