Mazda 2013 CX-9 - Instrument Cluster and Indicators; Meters and Gauges

Meters and Gauges
Speedometer ...................................................................................................... page 5-46
Odometer, Trip Meter and Trip Meter Selector .................................................. page 5-46
Tachometer ........................................................................................................ page 5-47
Engine Coolant Temperature Gauge ......................................................... ......... page 5-47
Fuel Gauge ................................................................................ ........................ page 5-48
Dashboard Illumination ......................................... ............................................ page 5-48
NOTE
When the ignition is switched ON, the dashboard gauges illuminate.
Driving Your Mazda
Instrument Cluster and Indicators
5-45
