Engine Compartment Overview
Power steering fluid reservoir
Windshield washer fluid reservoir
Power steering fluid reservoir
Windshield washer fluid reservoir
Engine coolant reservoir Fuse block
Engine coolant reservoir
Engine oil-filler cap
Engine oil-filler cap
Engine oil dipstick
Engine oil dipstick
Brake/Clutch fluid reservoir
Brake/Clutch fluid reservoir
Battery
Battery
Fuse block
Automatic transaxle fluid-level dipstick
(Only for automatic transaxle)
MZR 2.0 and MZR 2.5
SKYACTIV-G 2.0
Maintenance and Care
Owner Maintenance
8-19
