R099/13
Page 2 of 19
REPAIR PROCEDURE
MZD CONNECT Software Version Verification Procedure
Note:
When the system is updated, all factory default settings are restored and personal settings
(such as display and sound adjustments) are lost, including favorites information and phones
paired with the system.
1. Make sure the IG switch is “OFF”.
NOTE: All electrical loads should be turned off during the reflashing process, especially the
air conditioner (blower), rear defogger, and room lamps.
2. Install the ROOM FUSE and AUDIO FUSE to the fuse block in engine room (if not
installed).
Press the START/STOP ENGINE push button 1 time without depressing the clutch pedal
(manual transaxle) or the brake pedal (automatic transaxle), to switch the ignition position to
ACC.
NOTE: The engine starts by pressing the push button start while depressing the clutch
pedal (manual transaxle) or the brake pedal (automatic transaxle). To switch the ignition
position without starting the engine, press the START/STOP ENGINE push button without
depressing the pedal.
Confirm that the push button start indicator light (A) is illuminated (amber) and the display in
the instrument cluster is OFF (ignition position is in ACC).
3. Select “Settings” from the Home screen to check the software version.
