Mazda 3 - Fuse Block (Passengers Side)

Black plate (459,1)
Fuse block (Passenger's side)
1 4 7 10 13 16 19
5 8 11 14 17 20
6 9 12 15 18 21
28 3022 24 26
29 3123 25 27
32 33 34
2
3
DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
1 BOSE ――
2 P SEAT 30 A Power seat
í
3 P.WIND 30 A Power window
4 D.LOCK 25 A Power door lock
5 ―― ―
6 ―― ―
7 ESCL ――
8 SAS 15 A Air bag
9 ―― ―
10 HAZARD 15 A Hazard warning flashers, Turn signal lights
11 METER 15 A Instrument cluster
12 OUTLET 15 A Accessory sockets
13 R.WIPER 15 A Rear window wiper and washer
í
14 CIGAR 15 A Accessory sockets
15 ROOM2 ――
16 HEATER 10 A Air conditioner
17 MIRROR 10 A Power control mirror
18 ST SIG 10 A Engine control system
19 ―― ―
Maintenance and Care
Owner Maintenance
8-63
í
Some models.
