Vent Operation
Knob
Open
Close
qAdjusting the Vents
Directing airflow
You can direct air flow by moving the adjustment knob.
Horizontal air flow can be adjusted by press ing the vent left or right.
Adjusting the amou nt of airflow
These vents can be opened and closed with wheel.
NOTE
When using the air conditioner, mist may come out from the vents. This is not a sign of
trouble but a result of humid air being suddenly cooled.
Interior Comfort
Climate Control System
6-3
