3. Remove the metal stiffeners from the
blade rubber and install them in new
blades.
CAUTION
Don't bend or discard the stiffeners.
You need to use them again.
4. Carefully insert the new blade rubber.
Then inst all the blade assembly in the
reverse order of removal.
8-26
Maintenance and Care
Owner Maintenance
