qCapacities
(Approximate Quantities)
Item
Unit
L US qt Imp qt
Engine oil
With oil filter replacement 4.3 4.5 3.8
Without oil filter replacement 3.9 4.1 3.4
Coolant 7.0 7.4 6.2
Manual transaxle oil 2.87 3.03 2.53
Automatic transaxle fluid 7.2 7.6 6.3
Fuel tank 60 15.9 (US gal) 13.2 (Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
qDimensions
Item Vehicle specification
Overall length 4,610 mm (181.5 in)
Overall width 1,755 mm (69.1 in)
Overall height 1,630 mm (64.2 in)
Front tread 1,530 mm (60.2 in)
Rear tread 1,515 mm (59.6 in)
Wheelbase 2,750 mm (108.3 in)
qWeights
Item Weight
GVWR (Gross Vehicle Weight Rating) 2,074 kg (4,572 lb)
GAWR (Gross Axle Weight Rating)
Front 1,006 kg (2,218 lb)
Rear 1,068 kg (2,355 lb)
qAir Conditioner
Gas complies with SAE J639 Maximum operating charge
HFC134a (R-134a) 0.5 kg (17.55 oz)
Specifications
10-5
