Meters and Gauges
Speedometer .................................................. .................................................... page 5-29
Odometer, Trip Meter and Trip Meter Selector .................................................. page 5-29
Tachometer ....................................................................................... ................. page 5-30
Engine Coolant Temperature Gauge .................................................................. page 5-30
Fuel Gauge ........................................................................................................ page 5-31
Dashboard Illumination ............................................................. ........................ page 5-31
5-28
Driving Your Mazda
Instrument Cluster and Indicators
