4. Pull the strap and lift the end of the
seat-bottom up and forward.
5. If the armrest and storage box are in
the position for use, store them.
Refer to Storage Box on page 6-57.
6. Raise the lever and fold the seatback
forward.
CAUTION
l
When folding a seatback, always
hold onto the seatback with your
other hand while operating the lever.
If the seatback is not supported, it
will flip forward suddenly and could
cause injury.
l
When folding the seatback of the
right second-row seat, make sure the
storage box is stowed. If the storage
box is not stowed, it could be
damaged.
NOTE
To create a flat luggage compartment
space from the rear of the vehicle to the
back of the front seats, fold the second-
row and third-row seats (page 2-13).
2-10
Essential Safety Equipment
Seats
Mazda5_8W75-EA-06J_Edition1 Page22
Thursday, October 12 2006 5:10 PM
Form No.8W75-EA-06J
