2. Remove the screws with a Phillips
screwdriver and remove the rear
combination component.
3. Turn the socket and bulb assembly
counterclockwise and remove it.
4. Disconnect the bulb from the socket.
Reverse lights
Rear turn signal lights
Brake lights/Taillights
5. Install the new bulb in the reverse order
of removal.
License plate lights
1. Remove the liftgate cover.
2. Pull the socket and bulb assembly and
remove it.
3. Disconnect the bulb from the socket.
4. Install the new bulb in the reverse order
of removal.
Maintenance and Care
Owner Maintenance
8-43
