CAUTION
To prevent damage to the wiper arm
and other components, don't try to
sweep the wiper arm by hand.
1. Remove the cover and raise the wiper
arm.
2. Firmly rotate the wiper blade to the
right unti l it unlocks, then remove the
blade.
CAUTION
To prevent damage to the rear
window l et the wiper arm down
easily, don't let it slap down on the
rear win dow.
3. Pull down the blade rubber and sli de it
out of the blade holder.
4. Remove the metal stiffeners from each
blade rubber and install them in the
new blade.
CAUTION
Don't bend or discard th e stiffeners.
You need to use them again.
8-30
Maintenance and Care
Owner Maintenance
