qFront Passenger Air Bag
The front passenger air bag is mounted in the front passenger dashboard. The inflation
mechanism for the front passenger air bag is the same as the drive r's air bag, as mentioned
above.
For more details about air bag deployment, refer to “ SRS Air Bag Deployment Criteria”
(page 2-58).
(With Driver and Front Passenger Occupant Classification System)
In addition, the front passen ger air bag is designed to only deploy in accordance with the
total seated weight on the front passenger seat. For details, refer to the driver and front
passenger occupant classification system (page 2-61).
qSide Air Bags
The side air bags are mounted in the outboa rd sides of the front seatbacks.
When the air bag crash sensors detect a side imp act of greater than moderate force, the
system inflates the side air bag only on the side in which the vehicle was hit. The side air
bag inflates quickly to reduce injury to the driver or front passenger's chest caused by
directly hitting interior parts such as a door or window.
For more details about air bag deployment, refer to “ SRS Air Bag Deployment Criteria”
(page 2-58).
Essential Safety Equipment
SRS Air Bags
2-55
