In Case of Emergency
6-16
NUMBER
AMP
RATING
DESCRIPTION
1 50A I/P Fuse Panel
2 — Not Used
3 — Not Used
4 — Not Used
5 — Not Used
6 50A ABS Pump Motor
7 30A Powertrain Control Module
8 20A Power Door Locks and Remote Entry
9 — —
10 — —
11 50A Starter Relay Ignition Switch
12 10A PCM Memory
13 20A 4x4 Motor
14 — —
15 — —
16 40A Blower Motor
NUMBER
AMP
RATING
DESCRIPTION
17 — —
18 — —
19 — —
20 — —
21 10A PCM Memory
22 — —
23 20A Fuel Pump Motor
24 30A Headlights
25 10A A/C Clurtch
26 — —
27 — —
28 30A 4W ABS Module
29 — —
30 15A T railer T ow
31 20A Fog Lamps, Day T ime Running Lamps (DRL)
32 — —
