Mazda B2300 2001 - Page 265

In Case of Emergency
6-17
NUMBER
AMP
RATING
DESCRIPTION
33 15A Park Lamp
34 — —
35 — —
36 — —
37 — —
38 10A Left Headlamp Low Beam
39 — —
40 — —
41 — Heated Oxygen Sensors
42 10A Right Headlamp Low Beam
43 — —
44 — —
45A — W iper High/Low
45B — W iper Park/Run
46A — Not Used
NUMBER
AMP
RATING
DESCRIPTION
46B — Front W asher Pump
47A — Not Used
47B — Not Used
48A — Fog Lamp
48B — Fog Lamp Relay
49 — Full Starter
50A — Not Used
50B — Fuel Pump
51 — Not Used
52 — Not Used
53 — Powertrain Control Module (PCM) Diode
54 — Powertrain Control Module (PCM) Diode
55 — Blower
56A — A/C Clutch Solenoid
56B — T railer T ow
