Maintenance
8-39
1. Pull the wiper arm away from the
windshield and lock into the service
position.
2. Turn the blade at an angle from the
wiper arm. Push the lock pin with a
screwdriver to release the blade and
pull
the wiper blade down toward the
windshield
to remove it from the
arm.
3. Attach
the new wiper to the wiper arm
and press it into place until
a click is
heard.
CAUTION
To
prevent damage to the windshield,
don’t let the wiper arm fall on it.
NOTE
Install the blade so that the tabs are
toward
the bottom of
the wiper arm.
J Battery
WARNING
Battery:
Batteries are dangerous. To avoid
injury, pay careful attention to the
advice below.
Keep all flames, sparks, and lit
smoking materials away from the
battery.
Battery
cells contain hydro
-
gen, a highly combustible gas.
Keep batteries, which contain
SULFURIC
ACID, out of the
reach
of
children. Prevent battery contact
with skin, eyes, clothing, and the
vehicle.
(Continued)
