DTC C0051:62/C0051:64/C0051:67/C0051:85 [DYNAMIC STABILITY CONTROL (DSC)]
http://am.mazdaserviceinfo.com/emazda/dealersystem/service/esi/en_us/SM/2013/CX5/mv/books/mvw04/html/id0402b2906200.html[1/7/13 9:29:24 AM]
POSSIBLE
CAUSE
Improper installation of the EPS CM
EPS CM malfunction
Connector or terminal malfunction
SYSTEM
WIRING
DIAGRAM
—
Diagnostic procedure
STEP INSPECTION ACTION
1
PERFORM EPS CM DTC INSPECTION
Perform the EPS CM DTC inspection.
(See
ELECTRIC POWER STEERING (EPS)
ON-BOARD DIAGNOSIS
.)
Are any DTCs present?
Yes Go to the applicable DTC inspection.
(See
ELECTRIC POWER STEERING (EPS) ON-
BOARD DIAGNOSIS
.)
No Go to the next step.
2
VERIFY THAT THE SAME DTC IS NOT PRESENT
Clear the DTCs from the memory.
(See
ON-BOARD DIAGNOSIS [DYNAMIC
STABILITY CONTROL (DSC)]
.)
Start the engine and drive the vehicle
at 10 km/h {6.2 mph} or more.
Are the same DTCs present?
Yes Repeat the inspection from Step 1.
If the malfunction recurs, replace the EPS
CM, then go to the next step.
(See
STEERING WHEEL AND COLUMN
REMOVAL/INSTALLATION
.)
No Go to the next step.
3
VERIFY THAT NO OTHER DTCS ARE PRESENT
Are any other DTCs output?
Yes Go to the applicable DTC inspection.
(See
ON-BOARD DIAGNOSIS [DYNAMIC
STABILITY CONTROL (DSC)]
.)
No DTC troubleshooting completed.
