DTC U0001:88/U0100:00/U0101:00/U0114:00/U0131:00/U0155:00 [DYNAMIC STABILITY CONTROL (DSC)]
http://am.mazdaserviceinfo.com/emazda/dealersystem/service/esi/en_us/SM/2013/CX5/mv/books/mvw04/html/id0402b2907100.html[1/7/13 9:30:14 AM]
FAIL-SAFE
FUNCTION
U0100:00
Illuminates the ABS warning light
*1
, and TCS/DSC indicator
light
*1
.
Tire pressure monitoring system warning light illuminates
after flashes. (Not illuminated/flashed depending on
malfunction content.)
Inhibits the ABS
*2
, TCS
*2
, DSC
*2
, roll over mitigation
(ROM)
*2
, brake assist control
*2
, hill launch assist (HLA)
*2
,
and TPMS
*2
controls.
U0101:00
Illuminates the TCS/DSC indicator light.
Tire pressure monitoring system warning light illuminates
after flashes.
Inhibits the TCS, DSC, roll over mitigation (ROM), hill
launch assist (HLA), and TPMS controls.
U0114:00
Tire pressure monitoring system warning light illuminates
after flashes.
Inhibits the TPMS control.
U0131:00
Illuminates the TCS/DSC indicator light.
Tire pressure monitoring system warning light illuminates
after flashes.
Inhibits the TCS, DSC, roll over mitigation (ROM), and TPMS
controls.
U0155:00
Illuminates the ABS warning light
*1
and TCS/DSC indicator
light
*1
.
Tire pressure monitoring system warning light illuminates
after flashes. (Not illuminated/flashed depending on
malfunction content.)
Inhibits the ABS
*2
, TCS
*2
, DSC
*2
, roll over mitigation
(ROM)
*2
, brake assist control
*2
, hill launch assist (HLA)
*2
,
and TPMS
*2
controls.
*1
: Not illuminated depending on malfunction content.
*2
: Enabled depending on malfunction content.
CAN system wiring harness open or short circuit
CAN system wiring harness open or short circuit with PCM
