FOREWORD [DYNAMIC STABILITY CONTROL (DSC)]
http://am.mazdaserviceinfo.com/emazda/dealersystem/service/esi/en_us/SM/2013/CX5/mv/books/mvw04/html/id0402b2892400.html[1/7/13 9:28:30 AM]
CONTROLLER AREA NETWORK (CAN) MALFUNCTION DIAGNOSIS FLOW
Action for non-repeatable malfunction
If the malfunction does not recur, verify the malfunction cause by performing the following actions:
Verify that a DTC has been recorded in the memory using the M-MDS. (See ON-BOARD DIAGNOSIS
[DYNAMIC STABILITY CONTROL (DSC)]
.)
Perform a simulation test in the simulation mode based on the repair order form, record the data at that
time, and detect the malfunction cause.
Shake the wiring harness or connector of the electrical component which is suspected to be the cause of
the malfunction, and inspect for the occurrence of any malfunction or DTCs.
Inspect the female terminals for poor connection.
