2013 - CX-5 - Brakes
DTC U0423:00 [DYNAMIC STABILITY CONTROL (DSC)]
DTC U0423:00 Abnormal message from instrument cluster
DETECTION
CONDITION
Correct data cannot be received from instrument cluster
FAIL-SAFE FUNCTION
Tire pressure monitoring system warning light illuminates after
flashes.
Inhibits the TPMS controls.
POSSIBLE CAUSE
Instrument cluster malfunction
SYSTEM WIRING
DIAGRAM
—
Diagnostic procedure
STEP INSPECTION ACTION
1
INSPECT FOR INSTRUMENT CLUSTER
MALFUNCTION
Switch the ignition to off.
Using the M-MDS, perform the DTC
inspection for the instrument
cluster.
(See
DTC INSPECTION
[INSTRUMENT CLUSTER]
.)
Are any DTCs detected?
Yes Go to applicable DTC inspection.
(See
DTC TABLE [INSTRUMENT CLUSTER].)
No Go to the next step.
2
VERIFY THAT THE SAME DTC IS NOT PRESENT
Clear the DTCs from the memory.
(See
ON-BOARD DIAGNOSIS
[DYNAMIC STABILITY CONTROL
(DSC)]
.)
Are the same DTCs present?
Yes Repeat the inspection from Step 1.
If the malfunction recurs, replace the
instrument cluster, then go to the next step.
(See
PCM REMOVAL/INSTALLATION [SKYACTIV-
G 2.0]
.)
To Next Page
