Warning/Indicator Lights
Instrument Cluster varies depending on model and specifications.
Instrument Cluster
Center of Dashboard
Warning lights will appear in any of the highlighted areas
▼
Warning Indication/Warning Lights
These lights turn on or flash to notify the user of the system operation status or a system
malfunction.
Signal Warning Page
Brake System Warning Indication/Warning Light
*1*2
7-23
ABS Warning Light
*1
Electronic Brake
Force Distribu-
tion System
Warning
7-23
ABS warning
7-26
Charging System Warning Indication/Warning Light
*1
7-23
Engine Oil Warning Light
*1
7-23
(Red)
High Engine Coolant Temperature Warning Light
*1
7-23
Power Steering Malfunction Indication 7-23
When Driving
Instrument Cluster and Display
4-41
