Mazda L3 - Page 45

B–28
ENGINE
25. Install the engine front cover upper blind plug.
Tightening torque:
10 N·m {1.0 kgf·m, 7.4 ft·lbf}
26. Install the cylinder block lower blind plug.
Tightening torque:
20 N·m {2.0 kgf·m, 14.8 ft·lbf}
27. Install the new engine front cover lower blind
plug.
Tightening torque:
12 N·m {1.2 kgf·m, 8.9 ft·lbf}
End Of Sie
AME2212W003
AME2212W012
AME2212W002
