Mazda MX-30 2020 - Instrument Cluster and Display

Instrument Cluster and
Display
▼
Instrument Cluster and Display
① Instrument Cluster.......... page 4-10
② Active Driving Display..... page 4-27
Instrument Cluster
▼
Instrument Cluster
① Power Meter...................page 4-11
② Multi-information Display...............
..................................... page 4-12
③ High Voltage Battery Power
Gauge............................page 4-15
④ High Voltage Battery Temperature
Gauge............................page 4-15
⑤ Instrument Panel Illumination
Switch............................page 4-16
⑥ Speedometer..................page 4-10
⑦ TRIP Switch.................... page 4-14
▼
Speedometer
The speedometer indicates the speed
of the vehicle.
When Driving
Instrument Cluster and Display
4-10
