x
The system may have a malfunction if a message indicating a system malfunction is
displayed. Have your vehicle inspected by an expert repairer (we recommend an
Authorised Mazda Repairer).
x
A message may be displayed even when the ambient temperature is extremely
cold, or mud, ice, or snow adheres to the sensor area. Remove any foreign matter
from the sensor area.
▼
Sensor Detection Range
The sensors detect obstructions within the following range.
1. Front ultrasonic sensor detection range
2. Rear corner/Rear side ultrasonic sensor detection range
3. Rear ultrasonic sensor detection range
4. Front corner ultrasonic sensor detection range
A About 55.0 cm (About 21.6 in)
B
About 150 cm (About 59.0 in)
C About 100 cm (About 39.3 in)
When Driving
Parking Sensor System
4-215
