Specifications
▼
Charge System
Item Servicing data
Input power 220 - 240 V AC
Rated frequency 50 Hz
Maximum rated electrical current 32 A (normal charge)
Maximum power consumption 7.68 kVA (normal charge)
Maximum charging current 100 A (quick charge)
Electrical leakage detection current
for control box including genuine
charge lead
20 mA
EV charge mode/Connection type
Normal charge: Mode 2, mode 3, mode 4
Quick charge: CCS2 (Combo2)
Installation requirements
(information on protection against
short-circuit current and equipment
protection)
Applicable laws and regulations, and standards must be followed
for protection measures against over-current and over-voltage.
Always make sure to install appropriate over-current protection
devices to the wiring of houses and buildings.
IP level
IP44: When charge connector is connected to charge inlet
IP67: Charge lead
Operating temperature
Onboard charger: -30 °C (-22 °F) ʊ 65 °C (149 °F) (coolant
temperature). Performance degrades at 60 °C (140 °F) or higher
Charge lead: -40 °C (-40 °F) ʊ 65 °C (149 °F) (ambient temper-
ature)
Storage temperature
Onboard charger: -40 °C (-40 °F) ʊ 65 °C (149 °F) (coolant
temperature), -40 °C (-40 °F) ʊ 85 °C (185 °F) (ambient tem-
perature)
Charge lead: Vehicle guaranteed temperature
Applicable standards
Onboard charger:ࠉEN/IEC 61851-1, EN/IEC 61851-21,
EN/IEC 61851-23
Charge lead: EN/IEC 62196-1, EN/IEC 62196-2
Adapters
Do not use an adapter on the charge plug and the charge con-
nector.
Do not use an extension lead.
Specifications
Specifications
9-3
