Speed symbol Maximum permissible speed
T Up to 190 km/h (118 mph)
U Up to 200 km/h (124 mph)
H Up to 210 km/h (130 mph)
V Up to 240 km/h (149 mph)
W Up to 270 km/h (167 mph)
Y Up to 300 km/h (186 mph)
ZR Over 240 km/h (149 mph)
Tyre and
inflation
pressure
NOTE
The tyres have been optimally matched with the chassis of your vehicle.
When replacing tyres, Mazda recommends that you replace tyres of the same type
originally fitted to your vehicle. For details, contact an expert repairer (we
recommend an Authorised Mazda Repairer).
Check the tyre pressure label for tyre size and inflation pressure.
x
Refer to Tyre Inflation Pressure on page 6-26.
x
Refer to Tyre Pressure Label on page 9-2.
Standard tyre
Tyre size
Inflation pressure
Up to 3 persons ʊFull load
215/55R18 95H
Front 250 kPa (2.5 bar, 36 psi) 270 kPa (2.7 bar, 39 psi)
Rear 260 kPa (2.6 bar, 38 psi) 290 kPa (2.9 bar, 42 psi)
1 person's weight: About 75 kg
Winter tyre
Tyre size
Inflation pressure
Up to 3 persons ʊFull load
215/55R18
*1
M+S
Front 250 kPa (2.5 bar, 36 psi) 270 kPa (2.7 bar, 39 psi)
Rear 260 kPa (2.6 bar, 38 psi) 290 kPa (2.9 bar, 42 psi)
1 person's weight: About 75 kg
*
1 Load index and Speed Symbol: 95Q/95S/95H
Wheel nut tightening torque
When installing a tyre, tighten the wheel nut to the following torque.
108ʊ147 N·m (12ʊ14 kgf·m, 80ʊ108 ft·lbf)
Specifications
Specifications
9-6
