5. Remove the seat belts from the belt
guides.
Belt guide
6. Slide the seats forward.
Refer to Seat Slide on page 2-2.
7. Fold the seatbacks forward.
Refer to Seat Recline on page 2-2.
8. Pull the levers and fully relea se the side
latches.
Side latch
Lever
9. After the side latches are fully released,
release the lever.
10. Lift the side latches while pulling the
lever. Make sure the hooks are fully
released.
Side
latch
Lever
Hook
11. Disconnect the rear window defroster
cord connector from the plug on the
inside of the hardtop.
3-46
Knowing Your Mazda
Doors and Locks
