qSide Air Bag System Components
í
(2)
(1)
(3)
(4)
(1) Crash sensor and diagnostic module (SAS unit)
(2) Side crash sensors
(3) Side inflators and air bags
(4) Seats
Essential Safety Equipment
SRS Air Bags
2-37
í
Some models.
