Mazda MX-5 Miata 2004 - Instrument Cluster and Indicators; Meters and Gauges

5-18
Driving Your Mazda
Form No. 8S15-EA-03G
Instrument Cluster and Indicators
1 Speedometer ..............................................................................................................5-19
2 Odometer, Trip Meter and Selector...........................................................................5-19
3 Tachometer ................................................................................................................5-20
4 Engine Coolant Temperature Gauge .........................................................................5-20
5 Fuel Gauge ............................................................................................................... 5-21
6 Engine Oil Pressure Gauge .......................................................................................5-21
Meters and Gauges
