Convertible Top (Power Retractable Hardtop)
í
The power retractable hardtop opens/ closes electrically by operating switch es in the
vehicle. When opening/closing the hardt op, the hardtop, deck and window glass operate
together. The hardtop is stored in the storage area under the deck.
Top latch assembly
Close switch
Open switch
Deck
Indicator light
Hardtop
Knowing Your Mazda
Doors and Locks
3-49
í
Some models.
