qReplacing a Bulb (Interior)
Overhead light/Map lights (Front)
1. Remove the screws with a Phillips
screwdriver.
2. Wrap a flathead screwdriver with a soft
cloth to prevent damage to the trim and
gently insert it in the overhead ligh t as
shown in the figure, and then remo ve
the overhead light unit.
3. Turn the socket and bulb assembly
counterclockwise and remove it.
4. Disconnect the bulb from the socket.
5. Install the new bulb in the reverse order
of removal.
Overhead light (Rear), Courtesy lights,
Vanity mirror lights
1. Wrap a small flathead screwdriver with
a soft cloth to prevent damage to the
lens and remove the lens by careful ly
prying on the edge of the lens with the
screwdriver.
2. Disconnect the bulb by pulling it out.
Edge
Overhead light (Rear)
Courtesy lights
Edge
Maintenance and Care
Owner Maintenance
8-37
