Meters and Gauges
Speedometer ...................................................................................................... page 5-37
Speed Unit Selector ........................................................................................... page 5-37
Odometer, Trip Meter and Trip Meter Selector .................................................. page 5-37
Tachometer ........................................................................................................ page 5-38
Engine Coolant Temperature Gauge .................................................................. page 5-39
Fuel Gauge ........................................................................................................ page 5-39
NOTE
When the ignition is switched ON, the dashboard gauges illuminate.
