To change the seatback angle, press the
front or rear side of the reclining switch.
Release the switch at the desired posit ion.
qHeight Adjustment
To adjust the seat height, move the switch
up or down.
qSeat Position Memory
One-touch seat position programming and
a activation function are available on the
driver's seat.
CAUTION
When activating the seat position, do
not place your hands or fingers
around the seat bottom. The seat
moves to the desired position
automatically, and if your hands or
fingers are pla ced around the seat
bottom, it could cause injury.
SET button
Programming of the driver's seat positions
is possible using the following function:
l
Programming buttons 1, 2, or 3 and the
SET button.
Essential Safety Equipment
Seats
2-9
