Black plate (365,1)
Reverse lights
Rear side marker lights
4. Install the ne w bulb in the reverse order
of the removal procedure.
High-mount brake light
1. Wrap the end of a flathead screwdriver
in a soft cloth and remove the trunk
handle by insertin g the flathead
screwdriver in the position shown in
the figure and carefully prying the
handle off.
2. Disengage the pin in each clip securing
the trunk trim using a (
) screwdriver,
remove the screws and clips, and then
remove the trunk trim.
Removal
Installation
Maintenance and Care
Owner Maintenance
8-33
RX-8_8BQ7-EA-10H_Edition1 Page365
Wednesday, July 14 2010 11:52 AM
Form No.8B
