40 s or more
after turning the
ignition switch to
the LOCK
position
1.0 or less
• Related wiring
harness
D Ground GND
Under any condition:
Check for continuity to
ground.
Continuity GND
Door switch pressed. B+
F
Door
open/close
Door switch
Door switch released. 1.0 or less
• Door switch (See
DOOR SWITCH
INSPECTION )
• Related wiring
harness
Turn the ignition switch to
the ON position.
B+
G IG1
Ignition
switch
Turn the ignition switch to
the LOCK position.
1.0 or less
• Ignition switch
(See IGNITION
SWITCH
INSPECTION )
• Related wiring
harness
H
Power
supply
Power
window 30 A
fuse
Under any condition B+
• Power window 30
A fuse
• Related wiring
harness
