POWER OUTER MIRROR INSPECTION
1. Apply battery positive voltage and connect the ground to the corresponding power outer mirror
terminals, and then inspect the operation of the power outer mirror.
• If not as specified, replace the power outer mirror.
Terminal
Operation
B+ GND
Up B D
Down D B
Left F D
Right D F
2. Inspect for continuity between the power outer mirror heater terminals.
• If not as specified, replace the power outer mirror.
