Turn the
washer
switch to
the ON
position.
B+
(See RELAY
INSPECTION .)
• Windshield wiper
and washer switch
(See
WINDSHIELD
WIPER AND
WASHER
SWITCH
INSPECTION .)
• Related wiring
harnesses
Light switch at ON
position.
B+
E Headlight
Headlight
relay
Except above 1.0 or less
• Headlight relay
(See RELAY
INSPECTION .)
• Related wiring
harnesses
F GND Body ground
Under any condition:
Inspect for continuity to
ground.
Continuity
detected
• GND
• Related wiring
harnesses
