Mazda RX8 - Page 164

Manual Seat (RH)
1 Recliner lever
2 Side cover
3 Reverse cover
4 Front buckle
5 Cover
6 Seat back trim
7 Seat back pad
8 Seat back frame
9 Side air bag cover
10 Seat cushion trim
11 Seat cushion pad
12 Seat cushion frame
13 Slide adjuster
(w) RX-8 Body
Page 164
