SLIDE MOTOR INSPECTION
1. Disconnect the slide motor connector.
2. Connect battery positive voltage to slide motor terminal A or B, then verify that the slide motor operate
as shown in the table.
• If the slide motor does not operate as indicated in the table, replace the slide motor.
Connection
Motor operation
B+ GND
Forward B A
Backward A B
RECLINER MOTOR INSPECTION
1. Disconnect the recliner motor connector.
2. Connect battery positive voltage to recliner motor terminal A or B, then verify that the recliner motor
operate as shown in the table.
• If the recliner motor does not operate as indicated in the table, replace the recliner motor.
Connection
Motor operation
B+ GND
Forward A B
Backward B A
