6. Disconnect the connector.
7. Remove screws B, then remove the discharge headlight control module.
8. Install in the reverse order of removal.
DISCHARGE HEADLIGHT SYSTEM INSPECTION
Discharge headlight inoperative
WARNING:
• Incorrect servicing of the discharge headlights could result in electrical shock. Before servicing the
discharge headlights, always refer to the discharge headlight service warnings. (See DISCHARGE
HEADLIGHT SERVICE WARNINGS .)
Terminal layout
Inspection
procedure
STEP INSPECTION ACTION
1 Yes Go to Step 6.
