1
Connector
(See Connector Removal Note .)
2 Bolt A
3 Bolt B
4 Front door
5 Nut
6 Checker
7 Bolt C
8 Front door hinge
5. Install in the reverse order of removal.
6. Adjust the front door. (See DOOR ADJUSTMENT .)
Connector Removal Note
1. Pull the rubber boot outward.
2. Pull down the lever in the direction indicated by the arrow and disconnect the connector.
