REAR DOOR REMOVAL/INSTALLATION
1. Disconnect the negative battery cable.
2. Remove the rear seat cushion. (See REAR SEAT REMOVAL/INSTALLATION .)
3. Remove the seat belt rail. (See FRONT SEAT BELT REMOVAL/INSTALLATION .)
4. To remove the checker, remove the following parts:
a. Rear door lower trim (See REAR DOOR LOWER TRIM REMOVAL/INSTALLATION .)
5. To remove the rear door hinge, remove the following parts:
a. Rear seat cushion (See REAR SEAT REMOVAL/INSTALLATION .)
b. Tire house trim (See TIRE HOUSE TRIM REMOVAL/INSTALLATION .)
6. Remove in the order indicated in the table.
1 Connector
2 Bolt A
3 Bolt B
4 Rear door
5 Bolt C
6 Checker
7 Nut
8 Rear door hinge
7. Install in the reverse order of removal.
8. Adjust the rear door. (See DOOR ADJUSTMENT .)
