REAR DOOR ASSEMBLY/DISASSEMBLY
1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.
1 Rear door release handle
2 Rear door upper latch
3 Front seat belt retractor
4 Rear door lower latch
5 Rear door glass
6 Bracket
7 Catch pin
