Mazda RX8 - Page 214

warning
switch input
warning
switch
Hazard warning switch is
off.
B+
• Hazard warning
switch
(See HAZARD
WARNING
SWITCH
INSPECTION .)
• Related wiring
harnesses
Turn the
ignition switch
to the ON
position.
Turn
switch
(RH) is
on.
B+
I
Turn
switch (RH)
input
Turn switch
Except above 1.0 or less
• Turn switch
(See LIGHT
SWITCH
INSPECTION .)
• Related wiring
harnesses
Turn the
ignition switch
to the ON
position.
Turn
switch
(LH) is
on.
B+
J
Turn
switch (LH)
input
Turn switch
Except above 1.0 or less
• Turn switch
(See LIGHT
SWITCH
INSPECTION .)
• Related wiring
harnesses
(w) RX-8 Body
Page 214
