3 Rear door speaker
4. Install in the reverse order of removal.
REAR SPEAKER INSPECTION
1. Verify the resistance between rear speaker terminals.
• If the resistance is not within the specification, replace the rear speaker.
Resistance
o Standard: 4 ohms
o BOSE: 2 ohms
2. Connect a 1.5 V battery to the rear door speaker and verify that noise is sound from the rear door
speaker.
• If no sound is output, replace the rear door speaker.
FRONT TWEETER REMOVAL/INSTALLATION
1. Disconnect the negative battery cable.
2. Remove the inner garnish from the front door.
3. Remove the screws.
4. Remove the front tweeter.
5. Install in the reverse order of removal.
FRONT TWEETER INSPECTION
Standard
1. Verify the resistance between front tweeter terminals.
