MICROPHONE
AUDIOPILOT MICROPHONE REMOVAL/INSTALLATION
NOTE:
• "AudioPilot" is a registered trademark of Bose Corporation.
1. Disconnect the negative battery cable.
2. Remove the lower panel.(See LOWER PANEL REMOVAL/INSTALLATION .)
3. Remove in the order indicated in the table.
1 Connector
2 Screw
3 AUDIOPILOT microphone
4. Install in the reverse order of removal.
