AUDIO CONTROL SWITCH INSPECTION
1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module.(See DRIVER-SIDE AIR BAG MODULE
REMOVAL/INSTALLATION .)
3. Disconnect the audio control switch connector.
4. Verify the resistance and continuity between the audio control switch terminals.
• If the resistance and continuity are not as indicated in the tables, replace the audio control light
switch.
R:
Resistance.See the table.
Switch position Resistance (ohm)
VOL- switch ON
5156
VOL+ switch ON
140154
SEEK+ switch ON
286315
SEEK- switch ON
534589
MODE switch ON
9851,080
MUTE switch ON
1,9402,130
OFF
4,8005,290
