• Courtesy
light
All doors are closed. B+
MAP LIGHT
INSPECTION .)
• Interior light
(See INTERIOR
LIGHT
INSPECTION .)
• Courtesy light
• Door switch (See
DOOR SWITCH
INSPECTION .)
• Rear door upper
latch (See REAR
DOOR UPPER
LATCH
SWITCH
INSPECTION .)
• Rear door lower
latch (See REAR
DOOR LOWER
LATCH
SWITCH
INSPECTION .)
• Inspect related
harness.
While driver-side
door lock actuator is
unlocking.
1.0 or less→
B+→ 1.0 or less
1C Unlock output
Driver-side door
lock actuator
Other 1.0 or less
• Driver-side door
lock actuator
(See FRONT
DOOR LOCK
ACTUATOR
INSPECTION .)
• D.LOCK 15 A
fuse
While lock actuator
is locking.
1.0 or less→
B+→ 1.0 or less
1D Lock output
Door lock
actuator
Other 1.0 or less
• Front door lock
actuator (See
FRONT DOOR
LOCK
ACTUATOR
INSPECTION .)
• D.LOCK 15 A
fuse
1E GND Body ground
Under any
condition: Inspect
for continuit
y
to
Continuity
detected
GND
(w) RX-8 Body
