ground.
While passenger-
side lock actuator is
unlocking.
(Transmitter
UNLOCK button is
pressed twice within
5 s. )
1.0 or less→
B+→ 1.0 or less
1F Unlock output
Passenger-side
door lock
actuator
Other 1.0 or less
• Passenger-side
door lock
actuator (See
FRONT DOOR
LOCK
ACTUATOR
INSPECTION .)
• D.LOCK 15 A
fuse
2A Power supply
ROOM 15 A
fuse
Under any condition B+ ROOM 15 A fuse
Ignition switch at
ON
B+
2B IG1 Ignition relay
Ignition switch at
LOCK or ACC
1.0 or less
• Ignition relay
(See RELAY
INSPECTION .)
• D.LOCK 15 A
fuse
• Inspect related
harness.
Other B+
2C Horn on/off Horn relay
Transmitter LOCK
button is pressed
twice within 5 s .
B+→ 1.2 or
less→ B+
• Horn relay (See
RELAY
INSPECTION .)
• Inspect related
harness.
Hood is open. 5
2D
Hood
open/closed
Hood latch
switch
Hood is closed. 1.0 or less
• Hood latch
switch (See
HOOD LATCH
SWITCH
INSPECTION .)
• Inspect related
harness.
2E
Trunk lid
unlock
Trunk lid opener
relay
Transmitter trunk
lid button is pressed.
B+→ 1.2 or
less→ B+
(w) RX-8 Body
