All doors are closed.
(Door switch off)
B+
• Instrument
cluster (See
INSTRUMENT
CLUSTER
INSPECTION .)
• Door switch (See
DOOR SWITCH
INSPECTION .)
• Rear door upper
latch (See REAR
DOOR UPPER
LATCH
SWITCH
INSPECTION .)
• Rear door lower
latch (See REAR
DOOR LOWER
LATCH
SWITCH
INSPECTION .)
• Inspect related
harness.
Any transmitter
button is pressed
without key in
steering lock. (key
reminder switch off)
5→ 1.0 or less
2N ENABLE Keyless receiver
Key is in steering
lock. (key reminder
switch on)
5
• Keyless receiver
(See KEYLESS
RECEIVER
INSPECTION .)
• Inspect related
harness.
Any transmitter
button is pressed
without key in
steering lock. (key
reminder switch off)
1.0 or less →
changes
positively
2P DATA Keyless receiver
Key is in steering
lock. (key reminder
switch on)
1.0 or less
• Keyless receiver
(See KEYLESS
RECEIVER
INSPECTION .)
• Inspect related
harness.
Driver-side door is
locked.
1.0 or less
2Q
Lock input
(Driver-side
door lock-link
switch)
Driver-side door
lock-link switch
Driver-side door is
unlocked.
5
Driver-side door lock-
link switch (See
FRONT DOOR LOCK
ACTUATOR
INSPECTION .)
2R Unlock input
(Driver
side
Driver-side door
lock-link switch
Driver-side door is
locked.
5
Driver-side door lock-
link switch (See
